Radio Antenna FM-10 VF
Radio antenna FM-10 VF is used for analog radio signals reception in vertical polarization.
Radio Antenna FM-10 VF
- Channel (freq.): FM (87,5-108 MHz)
- No. of elements: 1
- Gain: Horizontal -1 dB(i) ; Vertical -2 dB(i)
- F/B ratio: 0 dB
- Beam width: Vertical 360°
- Antenna lenght: ─
- Impedance: 75 Ohm
- Coaxial cable connection: "F" female connector
- Inclination: 0°
- Antenna carrier: 18x12 mm
- Mounting on mast with outside diameter: 20-50 mm
-
This antenna can not be used in horizontal polarization.
-
