Electric fencers batteries

Electric fencers zinc air-saline batteries are SUITABLE FOR low and medium consumption energisers.
The usage period is in the range of 1 to 7 months.
You can connect the battery, then disconnect it and connect again after few months (because of low self-discharging).



Electric fencers batteries

Electric fencers batteries

ZINC AIR BATTERIES use atmospheric oxygen to produce electrochemical energy. Since one active material lies outside of the cell, the majority of the cell‘s volume contains the other actice component (zinc), so zinc air batteries have very high energy density. Using a reactant from the air saves on space, reducing the size and weight of the battery.

ZINC AIR-ALKALINE BATTERY
Higher discharge current (50mA or 150Ω).
Higher and constant voltage (8V).
Higher energy density (350Wh/kg).
Operating time: 2 years.

ZINC AIR-SALINE BATTERY
Lower discharge current (25mA or 300Ω).
Average voltage: 6V.
Energy density (150Wh/kg).
Operating time: 3 years (lower shelf-discharging).

ZINC AIR-SALINE BATTERIES use atmospheric oxygen (cathode) to produce electrochemical energy. The other active component is a zinc strip (anode). The electrolyte is an aqueous gel solution of ammonium and zinc chloride (separator).

  • High energy density: 150 Wh/kg.
  • Stable voltage level. Range of voltage: 1,5V; 5,4V; 9V
  • Range of capacity: 35 – 130Ah.
  • Require no maintenance and no special procedures before being ready to use.
  • Activated by removing label or stopper on the top of the battery.
  • Safe to handle, without any risk of leakage on fixed or moving installations.
  • Operating  time 3 years (capacity loss for each year is just 5%) – slow self-discharge rate.
  • Can be satisfactorily used at temperatures ranging from -5°C to +45°C.
  • Not subject to any special transport condition.
  • High reliability.
